廈門市哈德沃克電子科技有限公司大量現(xiàn)貨代理銷售英國Tyco泰科船用火災報警設備：探測器，報警按鈕，探頭底座等配件，原廠進口，常年現(xiàn)貨。
Tyco 601P-M 516.600.201
850PH, 851PH and 830PH Photo Heat Multi-Sensor Detectors
With its ability to detect a wide range of fires from flaming to smouldering types, the combined optical and heat multi-sensor
detector is the preferred choice for a range of applications including light industrial, retail and office environments.
It operates in a number of approved modes and sensitivities that can be dynamically selected to suit different environmental conditions.
Technical Specification
Detector material: Flame Retardant FR3010 ‘BAYBLEND’
Dimensions: Height 43mm
Dia.109mm
Colour: White
Weight: (Excluding Base)76g.
Voltage: 20 – 40 VDC
Quiescent Current: 380uA
Alarm Current: 3.3mA
Operating Temp: -25 °C to +70 °C
Storage Temp: -40 °C to +80 °C
Relative Humidity: 95% (noncondensing)
Approvals: EN54-5 and EN54- 7,CPD, VdS
Type Approval: CEA4021 851PH MED Approved
Product Codes
516.850.051
850PH Photo Heat Detector with built in line isolator
516.830.051
830PH Photo Heat Detector
516.850.055
851PH Photo-Heat Detector with built in line isolator Marine
